STA (Bullet Proof Aramid Fabric)
Bulletproof Conveyor Belts for High-Risk Environments
Our bulletproof conveyor belts are engineered to provide unmatched safety and resilience in high-risk environments. With advanced materials and construction, these belts offer exceptional protection against ballistic impact and other potential hazards. Designed for industries such as defense, security, and law enforcement, our bulletproof conveyor belts ensure the secure and reliable transport of materials while prioritizing the safety of personnel. Experience peace of mind knowing that your operations are equipped with the highest level of protection available. Trust our bulletproof conveyor belts for uncompromising safety and performance in challenging environments.
Send EnquiryIntroduction to Bullet Proof Conveyor Belt
STA Conveyor Belt occupies a unique position in the spectrum of steel reinforcing belts, thanks to its exceptional composition. It boasts the highest strength among conveyor belt reinforcements worldwide. In fact, STA surpasses E glass fiber, commonly used, by over triple the strength-to-weight ratio, and steel cord by five times. This remarkable strength also prevents bullet penetration, adding an extra layer of security.
Notably, STA Conveyor Belt offers more than continuous operation in temperatures ranging from 200°C to 300°C. Its fiber does not melt or burn, providing excellent heat resistance, even in instant contact temperatures up to 538°C.
STA stands out for its outstanding characteristics: lightweight, highly durable, corrosion-free, non-conductive, flexible, and five times stronger than steel cords in the air (20 times in water). This exceptional strength allows STA Belts to successfully replace steel cord conveyor belts worldwide. Furthermore, STA Belts offer tremendous power bill savings, an essential aspect of cutting production costs. By choosing STA Belts, you could potentially save lakhs of INR per annum.
Below are the different Applications and Technical Data related to STA Conveyor Belts:
CONVEYOR BELTING APPLICATIONS
- Carcass Constructions
- Reinforcement Comparison for Conveyor Belts
- Advantages of 'STA' vs. Steel
- Advantages of 'STA' vs. Other Textiles
TECHNICAL DATA
- Impact Resistance of 'STA'
- Fatigue Resistance
- Wear Resistance
APPLICATION OF 'STA'
- Underground Coal Mines
- Ore Mines
- Port Terminals
|
Tensile Strength
|
STA 630
|
STA 800
|
STA 1000
|
STA 1250
|
STA 1400
|
STA 1600
|
STA 1800
|
STA 2000
|
STA 2500
|
|
|
Top Cover Thickness
|
mm
|
6
|
6
|
6
|
8
|
8
|
8
|
8
|
10
|
10
|
|
Bottom Cover Thickness
|
mm
|
3
|
3
|
3
|
4
|
4
|
4
|
4
|
5
|
5
|
|
Belt Thickness
|
mm
|
11.0
|
11.0
|
11.6
|
14.8
|
15.3
|
15.35
|
15.4
|
18.5
|
19.0
|
|
Approx Belt Weight
|
kg/m2
|
11.65
|
11.8
|
12.0
|
15.7
|
16.4
|
16.6
|
16.9
|
19.8
|
20.45
|
|
Elongation at 10%
|
%
|
0.5
|
0.5
|
0.4
|
0.4
|
0.4
|
0.4
|
0.4
|
0.4
|
0.4
|
