General Purpose Conveyor Belt | M-24 Grade – image 1
General Purpose Conveyor Belt | M-24 Grade – image 2
General Purpose Conveyor Belt | M-24 Grade – image 3
General Purpose Conveyor Belt | M-24 Grade – image 4
General Purpose Conveyor Belt | M-24 Grade – image 5
General Purpose Conveyor Belt | M-24 Grade – image 6
General Purpose Belts

General Purpose Conveyor Belt | M-24 Grade

High-Quality Conveyor Belts for Heavy-Duty Applications

The M-24 grade conveyor belt is a widely used and versatile type of conveyor belt known for its durability and strength. Specifically designed to handle heavy-duty applications, it can withstand rigorous conditions, making it ideal for industries such as mining, construction, and cement plants. Manufactured using high-quality materials, the M-24 grade conveyor belt exhibits excellent resistance to abrasion, impact, and tearing.

Send Enquiry

Eye ON Conveyor Belt

First time in India Launched by Somi Conveyor Beltings Ltd.

Eye ON Conveyor Belt

Characteristics of Eye ON Conveyor Belt

  • Alarming & Control Over Inventory
  • No Extra Cost (at FOC Basis)
  • Makes the outlook of the conveyor system apprehensibly good
  • Manufacturer distinguished
  • Improved abrasion properties in comparison to old technical standard
  • Impact resistance
  • Kushnin technology
  • Light in weight — first time in India
  • Improved fatigue resistance
  • Elongation only 1.75%
  • Extra Thickness & better life
  • Available in M-24 & SAR Grade only

Benefits

Why industries trust M-24 grade belts

  • Manufactured and tested to strict quality control on upgraded equipment
  • Extreme tensile strength for heavy loads over long distances
  • Highly resistant to dynamic stress and sudden load variations
  • Capable of troughing up to 45 degrees
  • Low stretch maintains consistent belt tension with minimal adjustment
  • Non-rotting construction for wet and outdoor environments

Belts Rating and Range

  • Belt Rating: 250/2 to 2500/6
  • Width: Up to 2400 mm

SomiFlex - Belt Selection Chart Polyester/Nylon (EP) Belts

Belt TypeMax. Recommended Working Tension (kN/m)Nominal Carcass Thickness (mm)Carcass Weight (kg/m²)Pulley Diameters (mm)Min. Belt Width (mm)Maximum Belt Width for Satisfactory Load Support (mm)
Material Weight in Tons/m³
ABC< 0.750.75 - 1.51.5 - 2.52.5 - 3.2
SF250/2252.42.98315250200300800600--
SF315/231.52.73.35315250200400800800--
SF315/331.533.724003152504001000800650-
SF400/2403.13.5400315250400800800650-
SF400/3403.23.9740031525040012001000800-
SF400/4404.25.21500400315650140012001000-
SF500/3503.64.4650040031550012001000800-
SF500/4504.45.465004003156501600140012001000
SF500/5505.36.576305004006501600140012001000
SF630/36344.96500400315500140012001000800
SF630/4634.96.086305004006501600140012001000
SF630/5635.66.946305004008002000180016001400
SF800/3804.95.585004003156501600140012001000
SF800/4805.56.826305004006501800160014001200
SF800/5806.27.698006305008002000180016001400
SF1000/41006.27.698006305008002000200018001600
SF1000/510078.6880063050010002000200020001800
SF1000/61007.69.42100080063010002000200020002000
SF1250/41257.28.9380063050010002000200020002000
SF1250/51257.99.8100080063010002000200020002000
SF1250/61258.510.54100080063010002000200020002000
SF1400/41408.610.66100080063010002000200020002000
SF1600/51609.611.28100080063012002000200020002000
SF1600/616010.111.91250100080012002000200020002000
SF1800/518010.913.521250100080012002000200020002000
SF1800/618012.1151400125080012002000200020002000
SF2000/52001113.641250100080012002000200020002000
SF2000/620012.1151400125080012002000200020002000

SomiFlex - Belt Selection Chart Nylon/Nylon (NN) Belts

Belt TypeMax. Recommended Working Tension (kN/m)Nominal Carcass Thickness (mm)Carcass Weight (kg/m²)Pulley Diameters (mm) *Min. Belt Width (mm)Maximum Belt Width for Satisfactory Load Support (mm) **
Material Weight in Tons/m³
ABC< 0.750.75 - 1.51.5 - 2.52.5 - 3.2
SF250/2252.52.6315250200300800600--
SF315/231.52.72.9315250200400800800--
SF315/331.52.73.24003152504001000800650-
SF400/3403.23.540031525040012001000800-
SF400/4403.84.50400315650140012001000-
SF500/3503.5450040031550012001000800-
SF500/4504.24.85004003156501600140012001000
SF500/5504.95.66305004006501600140012001000
SF630/3633.84.5500400315500140012001000800
SF630/4634.85.46305004006501600140012001000
SF630/5635.76.16305004008002000180016001400
SF800/3804.85.15004003156501600140012001000
SF800/4805.36.16305004006501800160014001200
SF800/5806.26.88006305008002000180016001400
SF1000/41006.178006305008002000200018001600
SF1000/51006.87.880063050010002000200020001800
SF1000/61007.58.3100080063010002000200020002000
SF1250/41257.18.280063050010002000200020002000
SF1250/51257.88.9100080063010002000200020002000
SF1250/61258.39.4100080063010002000200020002000
SF1400/414089.8100080063010002000200020002000
SF1600/51609.510.4100080063012002000200020002000
SF1600/61601010.81250100080012002000200020002000
SF1800/518010.511.651250100080012002000200020002000
SF1800/618011.112.241400125080012002000200020002000

Applications & Industries

Where this conveyor belt excels

  • Mining industry - transporting coal, minerals, and materials
  • Cement plants - handling raw materials, clinker, and finished products
  • Steel plants - moving iron ore and coke to furnaces
  • Power plants - transporting coal and ash in high-temperature conditions
  • Construction sites and heavy material handling
  • Quarrying operations
  • General heavy-duty industrial applications
